Galvanized Welded Wire Mesh Roll/Panels
Hot dipped galvanized welded wire mesh having good corrosive resistance and qualities which are not usually found in average wire mesh.
Electro galvanized welded wire mesh is widely used in industry, farming, construction, transportation and mining for protection of structure, safety segregation, keeping of poultry and livestock, and decorations etc. welded wire mesh is characteristic of its fine qualities, sturdiness and durable, economy as well as attractiveness.
PVC coated and sprayed welded wire mesh has corrosion resistance, aging resistance, sunshine resistance and weather resistance. Colors available for PVC coated welded wire mesh: Green, blue, white or other colors at customers request.
Specifications
|
Materials
|
Low carbon/Galvanized iron wire/Stainless steel wire/PVC-coating iron
|
|
Length
|
1.0M-50M Can Corroding as Your inquiry for Customized
|
|
Width
|
0.5M-2.5M
|
|
Surface Treatment
|
Electro galvanized, hot dipped galvanized or PVC coated
|
|
Application:
|
Transportation and mining for all such purposes as poultry houses,Egg baskets,Runway enclosures,Draining rack,Fruit drying screen,Mesh Fence.
|
|
Mesh Opening
|
Wire Thickness
|
Mesh Width
|
|||
|
Inch
|
mm
|
bwg
|
mm
|
Inch
|
Meter
|
|
1/4×1/4
|
6.35×6.35
|
26.24.23.22.21
|
0.45-0.81
|
12-48
|
0.3-1.2
|
|
3/8×3/8
|
10×10
|
26-19
|
0.45-1.07
|
12-48
|
0.3-1.2
|
|
1/2×1/2
|
12.7×12.7
|
25-16
|
0.51-1.65
|
12-80
|
0.3-2.0
|
|
5/8×5/8
|
16×16
|
25-16
|
0.51-.165
|
12-80
|
0.3-2.0
|
|
3/4×3/4
|
19×19
|
25-16
|
0.51-1.65
|
12-80
|
0.3-2.0
|
|
1/2×1
|
13×25
|
22-14
|
0.71-2.11
|
12-80
|
0.3-2.0
|
|
1×1
|
25.4×25.4
|
22-14
|
0.71-2.11
|
12-80
|
0.3-2.0
|
|
2×2
|
60×60
|
18-12
|
1.25-2.77
|
12-80
|
0.3-2.0
|
|
2×3
|
50×75
|
16-12
|
1.65-2.77
|
12-80
|
0.3-2.0
|
|
2×4
|
50×100
|
16-12
|
1.65-2.77
|
12-80
|
0.3-2.0
|
|
3×3
|
75×75
|
16-12
|
1.65-2.77
|
12-80
|
0.3-2.0
|
|
3×4
|
75×100
|
16-12
|
1.65-2.77
|
12-80
|
0.3-2.0
|
|
4×4
|
100×100
|
16-12
|
1.65-2.77
|
12-80
|
0.3-2.0
|
|
6×6
|
150×150
|
16-12
|
1.65-2.77
|
12-80
|
0.3-2.0
|
